Panasonic TOUGHBOOK G2/G3 Standard Full Dock (Powered Serial, No RF)

$1,224.00

Item Number: 7160-2184-20

Description

Keep powered serial equipment part of the day’s work. The Standard Full dock brings powered RS-232, Ethernet and USB together around TOUGHBOOK® G3 or G2, giving compatible serial peripherals the connection they call for. Front USB-C stays accessible to the user while rear ports keep installed devices in place. The Standard design also accommodates compatible G2 field accessories, so the vehicle workspace can support crews through a tablet transition.

Add to Quote
Shipping — Approximate Lead Time Given at Order Entry
Where To Buy Where to Buy
URL copied to clipboard
Product Sheet Installation Guide
View Full Line Catalog

  • Weight

    2.37 lbs / 1.08 kg

  • Height

    9.67 in / 24.56 cm

  • Width

    11.18 in / 28.40 cm

  • Depth

    5.25 in / 13.35 cm w / Studs 4.33 in / 11.00 cm w / o Studs

Features:

  • A dedicated place to connect. Bring the tablet and vehicle equipment together in one Standard workspace.
  • Keep a connection close. The front USB-C port stays accessible to the crew during the shift.
  • Free the front of the workspace. Rear USB and Ethernet ports support the gear that stays in the cab.
  • Give serial peripherals the port they need. Full replication adds powered RS-232 and DP Alt Mode on rear USB-C.
  • Match the vehicle installation. No RF pass-through suits vehicles that do not need external antenna connections.
  • Choose the power connection that fits. A compatible 15 VDC vehicle adapter is sold separately.
  • Keep the G2 setup intact. Supports compatible G2 extended battery, rear hand strap, smart card reader and bumper guards.
  • Built to keep up. TOUGHBOOK Certified and cycle tested through 30,000 docking, latch and lock uses.


Purchase this product through a Reseller in your area.

  • Model:

    • TOUGHBOOK G2
    • TOUGHBOOK G3

  • Device OEM:

    • Panasonic

  • Warranty:

    • 3 Year Limited Warranty
    • Extended Warranty/Gamber Guard Options Available

  • Power Supply:

    Power adapter is not included, please use one of the following:

    • Lind 120W Automobile Bare Wire Leads Power Adapter for Panasonic (7300-0461)
    • Power Adapter – Panasonic 120W – Auto Adapter (7300-0747)
    • LIND 12-32V Material Handling Isolated Power Adapter (7300-0464)
    • LIND 20-60V Material Handling Isolated Power Adapter (7300-0465)
    • LIND 72-110V Material Handling Isolated Power Adapter (7300-0417)

  • Testing Specifications:

    • TOUGHBOOK certification in progress
    • MIL-STD 810H Shock/Vibration Tested
    • MIL-STD 810H Environmental Testing: Humidity, High/low temperature, (storage/operational)
    • Cycle Tested: 30K cycles, docking connector, latching & locking mechanisms
    • RoHS, FCC, CE, UKCA
    • SAE J1455 Shock Crash Hazard Test

  • Port Replicators:

    • 1 x RJ45 Ethernet 1Gbps
    • 1 x USB-A 5Gbps, 1.5A
    • 1 x USB-C 5Gbps, 0.9A
    • 1 USB-C 5Gbps, 1.5A (With DP Alt Mode)
    • 1 x USB-C 480Mbps, 0.5A (Front)
    • 1 x RS-232 Serial
    • 1 x 15 VDC Power Input

  • Antenna Pass-through:

    • No RF

  • Device Type:

    • Tablet

  • Industry:

    • Fire/Rescue
    • Intermodal
    • Logistics
    • Material Handling
    • Public Safety
    • Utility

  • Port Replication:

    • Full

  • Brand:

    • Gamber-Johnson

  • Sub Type 1:

    • Dock
