DeX Heads Up Vehicle Kit Without Keyboard

$1,628.00

Item Number: 7170-0757-01

Description

If you have a keyboard and are looking for a Heads Up DeX vehicle solution, then use this kit which includes Gamber-Johnson’s 13.3″ Capacitive Touch Screen, a Rugged USB Hub, and Smartphone Dock Mounting Bracket; just add the appropriate Heads Up smartphone docking station to match your Samsung smartphone and bring your own keyboard to complete your ergonomic DeX vehicle solution.

Add to Quote
Shipping — Approximate Lead Time Given at Order Entry
Where To Buy Where to Buy
URL copied to clipboard
Product Sheet Installation Guide
View Full Line Catalog

  • Weight

    See Individual Components.

  • Height

    See Individual Components.

  • Width

    See Individual Components.

  • Depth

    See Individual Components.

Features:

  • Add a compatible Heads Up Smartphone Docking Station (7160-1394-00 Note9), (7160-1394-01 S9+), (7160-1394-02 S9), (7160-1394-03 S10+), (7160-1394-04 S10), (7160-1394-05 Note10), (7160-1394-06 Note10+), (7160-1394-07 S10e) to complete your DeX vehicle solution. Must order Separately.
  • Smartphone requires a Rebel phone case to be compatible with the smartphone docking station; (18551-00 Note9), (18551-01 S9+), (18551-02 S9), (18551-03 S10+), (18551-04 S10), (18551-05 Note10), (18551-06 Note10+) and (18551-07 S10e). Must order Separately.
  • This DeX Heads Up vehicle solution positions the smartphone dock next to the touchscreen where you can use your phone as a secondary screen or a touchpad device
  • Mount the 13.3" touch screen to a Gamber-Johnson close-to-dash mount (7160-1346 or 7160-0822) or tablet display mount (7160-0529 or 7160-0494) for optimal viewing
  • 13.3" 5-point capacitive touchscreen, high resolution 1920 x 1080, Brightness: 50-1000 nits (adjustable)
  • The Rugged USB Hub provides port replication to connect all peripherals; conceal under the instrument panel, or console box or mounted to the heads up mounting bracket
  • Gamber-Johnson offers several DeX solutions including:
    • The DeX Armrest vehicle solution that positions the smartphone dock in the vehicle armrest next to the driver where it is out of the way but still accessible
    • The DeX Desktop solution that enable the mobile worker to transition from vehicle to desktop seamlessly
    • Contact Gamber-Johnson for more information about their DeX solution kits and DeX components and accessories

Kit Includes:

  • 13.3" Touchscreen Display - Includes power cable, HDMI cable, USB Type B cable (7160-1451-00)
  • Rugged USB Hub - Includes USB-C cable (7160-1393-00)
  • Smartphone Dock Heads Up Articulating Mount (7110-1237)
  • Smartphone Dock Heads Up Mount Bracket (18540)
  • Installation Guides
  • Mounting Hardware

Purchase this product through a Reseller in your area.

  • Device OEM:

    • Samsung

  • Model:

    • Tab Active Pro

  • Testing Specifications:

    • MIL-STD 810G Shock and Vibration Specifications
    • MIL-STD 810G Temperature and Humidity (operational and storage)
    • SAE J1455 30mph Crash Testing

  • Port Replicators:

    13.3" Touchscreen Display (7160-1451-00)

    • (1) HDMI
    • (1) VGA
    • (1) USB type C (2A @ 5V) fast charging
    • (1) USB type B (for Touch Control)
    • (2) USB 3.0 (fast charging 1.5A)
    • (1) Aux. out 3.5 mm
    • (1) DC input (Barrel Jack)


    Rugged USB Hub (7160-1393-00)

    • (4) USB 3.0 (2) fast charging 1.5A
    • (1) Ethernet RJ45 (Gigabit)
    • (1) HDMI
    • (1) USB-C (5V@2A) fast charging
    • (1) Power port

  • Compliance:

    FCC; CE; RoHS; REACH

  • Brand:

    • Gamber-Johnson

  • Sub Type 1:

    • Accessories
    • Screen Mount

  • Notes:

    WARRANTY

    • 1 Year Limited Warranty
      • Touchscreen Display (7160-1451-00)
      • Rugged USB Hub (7160-1393-00)
    • Limited Lifetime Warranty
      • Smartphone Dock Heads Up Articulating Mount (7110-1237)
      • Smartphone Dock Heads Up Mount Bracket (18540)

    Dimensions

    • 13.3" Touchscreen Display (7160-1451-00)
      • Weight: 6.65 lbs / 3.02 kg
      • Height: 9.94 in / 25.25 cm
      • Width: 13.75 in / 34.93 cm
      • Depth: 1.57 in / 3.99 cm
    • Rugged USB Hub (7160-1393-00)
      • Weight: 0.25 lbs / 0.11 kg
      • Height: 2.05 in / 5.21 cm
      • Width: 4.36 in / 11.07 cm
      • Depth: 5.62 in / 14.27 cm
    • Smart Phone Heads Up Mounting Bracket (18540)
      • Weight: 0.74 lbs / 0.34 kg
      • Height: 0.5 in / 1.27 cm
      • Width: 12 in / 30.48 cm
      • Depth: 5.75 in / 14.61 cm
    • Heads Up Articulating Mount (7110-1237)
      • Weight: 0.2 lbs / 0.09 kg
      • Height: 2.75 in / 6.99 cm
      • Width: 2.12 in / 5.38 cm
      • Depth: 2.12 in / 5.38 cm
