Panasonic TOUGHBOOK® 56 TRIMLINE™ Lite Laptop Docking Station No RF

$1,449.00

Item Number: AS7.P056.100-G-GJ

Description

The Panasonic TOUGHBOOK® 56 TRIMLINE™ Lite Docking Station delivers essential port replication in a compact, streamlined design. Built for mobile professionals, it provides reliable connectivity and secure docking for everyday workflows.

This solution is ideal for applications that do not require RF pass-through, offering a practical and efficient docking option for in-vehicle and fixed environments.

Add to Quote
Shipping — Approximate Lead Time Given at Order Entry
Where To Buy Where to Buy
URL copied to clipboard
Product Sheet Installation Guide
View Full Line Catalog

  • Weight

    8.90 lbs / 4.04 kg

  • Height

    2.89 in / 7.34 cm

  • Width

    13.78 in / 35.00 cm

  • Depth

    12.28 in / 31.19 cm

Features:

  • CNC machined aircraft grade aluminum construction to ensure a lightweight, ultra-rugged solution in all mission critical operations
  • 75G-force shock tested - almost double the industry standard, to ensure ultimate safety during an extreme event
  • Black anodized and epoxy powder coat finishes provide years of durable, easy maintenance
  • Slim, low profile design offer maximum usable cabin space and ultimate vehicle operator comfort and safety
  • Genuine Panasonic electronics for maximum reliability
  • Connector pin protective cover to reduce risk of pin damage
  • Key lockable for increased theft deterrence
  • VESA 75 mounting pattern makes integration with existing mounting equipment simple and fast
  • Rear-facing connector ports with integrated cable tie rail offers organized and tidy wiring for a cleanly finished installation
    Docked / Undocked visual indicator
  • LED status indicator showing dock powered (red) / dock powered with computer connected (green)
  • Backwards compatible with TOUGHBOOK 55


Purchase this product through a Reseller in your area.

  • Model:

    • TOUGHBOOK 55
    • TOUGHBOOK 56

  • Device OEM:

    • Panasonic

  • Warranty:

    • 3 Year Limited Warranty

  • Power Supply:

    Power adapter is not included. Recommended Power Supply:

    • LIND 120W DC/DC power adapter (PA1580-4922-GJ)

  • Testing Specifications:

    • TOUGHBOOK Certified
    • 75G Shock
    • MIL STD 810 H
    • Vibration & Shock
    • Cycle Latch/Unlatch 30,000 cycles
    • Shock Crash Test Simulated 30mph sled crash test
    • Environmental
    • SAE J1455
    • FCC, CE, UKCA, RoHS

  • Port Replicators:

    • 1 x RJ45 Ethernet 1Gbps
    • 1 x USB-A 5Gbps, 1.5A
    • 1 x USB-C 5Gbps, 0.9A
    • 1 USB-C 5Gbps, 1.5A (Without DP Alt Mode)
    • 1 x USB-C 480Mbps, 0.5A (Front)
    • 1 x 15 VDC Power Input

  • Device Type:

    • Laptop

  • Industry:

    • Fire/Rescue
    • Intermodal
    • Logistics
    • Material Handling
    • Public Safety
    • Utility

  • Port Replication:

    • Lite

  • Brand:

    • PMT

  • Sub Type 1:

    • Dock
