Panasonic TOUGHBOOK G2/G3 Slim Full Dock (Powered Serial, Dual RF)

$1,393.00

Item Number: 7160-2186-22

Description

A crowded cab can still support a complete connection plan. This Slim Full dock brings powered RS-232, dual SMA RF pass-through, Ethernet and USB together in a 3.85-inch profile for TOUGHBOOK® G3 and G2. Vehicle antennas have their path to the tablet, compatible serial devices have the power they need, and front USB-C remains easy to reach. The result is a connected workspace that leaves more room for the rest of the installation.

Add to Quote
Shipping — Approximate Lead Time Given at Order Entry
Where To Buy Where to Buy
URL copied to clipboard
Product Sheet Installation Guide
View Full Line Catalog

  • Weight

    2.175 lbs / 0.99 kg

  • Height

    11.17 in / 28.37 cm

  • Width

    9.66 in / 24.54 cm

  • Depth

    3.85 in / 9.78 cm

Features:

  • Keep the cab open. Fit the tablet into a 3.85-inch-deep vehicle docking profile.
  • Connect within reach. Front USB-C makes it easier to attach a peripheral without reaching behind the tablet.
  • Keep fixed devices connected. Two rear USB-C ports, USB-A and 1Gbps Ethernet serve installed equipment.
  • Make room for powered serial. Powered RS-232 serves compatible peripherals; rear USB-C supports DisplayPort Alt Mode.
  • Keep external antennas in the plan. Dual SMA RF pass-through connects to the vehicle antenna setup.
  • Match power to the installation. Select a compatible vehicle power adapter separately.
  • Support the next tablet. TOUGHBOOK G3 docking also supports G2, helping fleets transition devices.
  • Confidence for mobile work. TOUGHBOOK Certified with MIL-STD-810H testing and a three-year limited warranty.


Purchase this product through a Reseller in your area.

  • Model:

    • TOUGHBOOK G2
    • TOUGHBOOK G3

  • Device OEM:

    • Panasonic

  • Warranty:

    • 3 Year Limited Warranty
    • Extended Warranty/Gamber Guard Options Available

  • Power Supply:

    Power adapter is not included, please use one of the following:


    • Lind 120W Automobile Bare Wire Leads Power Adapter for Panasonic (7300-0461)
    • Power Adapter – Panasonic 120W – Auto Adapter (7300-0747)
    • LIND 12-32V Material Handling Isolated Power Adapter (7300-0464)
    • LIND 20-60V Material Handling Isolated Power Adapter (7300-0465)
    • LIND 72-110V Material Handling Isolated Power Adapter (7300-0417)

  • Testing Specifications:

    • TOUGHBOOK certification in progress
    • MIL-STD 810H Shock/Vibration Tested
    • MIL-STD 810H Environmental Testing: Humidity, High/low temperature, (storage/operational)
    • Cycle Tested: 30K cycles, docking connector, latching & locking mechanisms
    • RoHS, FCC, CE, UKCA
    • SAE J1455 Shock Crash Hazard Test

  • Port Replicators:

    • 1 x RJ45 Ethernet 1Gbps
    • 1 x USB-A 5Gbps, 1.5A
    • 1 x USB-C 5Gbps, 0.9A
    • 1 USB-C 5Gbps, 1.5A (With DP Alt Mode)
    • 1 x USB-C 480Mbps, 0.5A (Front)
    • 1 x RS-232 Serial
    • 1 x 15 VDC Power Input

  • Antenna Pass-through:

    • Dual RF (SMA)

  • Device Type:

    • Tablet

  • Industry:

    • Fire/Rescue
    • Intermodal
    • Logistics
    • Material Handling
    • Public Safety
    • Utility

  • Port Replication:

    • Full

  • Brand:

    • Gamber-Johnson

  • Sub Type 1:

    • Dock
