Getac F110 Vehicle Docking Station with Getac 120W Auto Power Adapter with Bare Wire Lead (Tri RF)

$1,231.00

Item Number: 7170-0902-13

Description

Getac F110 vehicle docking station (Tri RF) with full port replication; easy one-hand docking/release; a keyed lock; and VESA 75mm mounting pattern to mount to a variety of Gamber-Johnson mounting equipment. Kit includes Getac auto power adapter. Now shipping.

Add to Quote
Shipping — Approximate Lead Time Given at Order Entry
Where To Buy Where to Buy
URL copied to clipboard
Product Sheet Installation Guide Testing Summary
View Full Line Catalog

  • Weight

    See Individual Components.

  • Height

    See Individual Components.

  • Width

    See Individual Components.

  • Depth

    See Individual Components.

Features:

  • Getac certified electronics
  • Compatible with the Getac F110 G7 tablet and all previous versions of the F110 tablet
  • Docking station accommodates the tablet's mag strip reader and rotating hand strap
  • Access to all tablet control buttons and ports while the tablet is docked
  • Downward-facing I/O ports; integrated cable strain relief and cable management system
  • Floating docking connector for reliable connectivity in the most rugged environments
  • One-hand docking and release for efficient use all day long
  • Keyed lock for theft deterrence
  • Gamber-Johnson rugged construction and reliability
  • Composite design for reduced weight and durability
  • VESA 75mm mounting pattern
  • TRI-RF SMA

Kit Includes:

  • Getac F110 Vehicle Docking Station
  • Getac 120W auto power adapter with bare wire lead
  • Mounting Hardware
  • Installation Instructions

Purchase this product through a Reseller in your area.

  • Model:

    • F110

  • Device OEM:

    • Getac

  • Warranty:

    • 3 Year Limited Warranty
    • Extended Warranty/Gamber Guard Options Available

  • Power Supply:

    • Getac 120W automotive power adapter with bare wire lead (7300-0516) is included with this kit.
      • Input voltage 12-32 VDC
      • Output voltage 19VDC
      • Output current 6.32 amps (max)
      • Bare wire lead

  • Testing Specifications:

    • Getac Certified
    • RoHS; FCC; CE; UKCA
    • MIL-STD 810H vibration testing: Operational/Non-operational
    • Shock crash hazard: SAE J1455; Mechanical Shock 40g
    • Environmental: Thermal Shock; Humidity; High/Low Temperature - Storage/Operational
    • EMI - Electromagnetic Interference
    • Cycle Testing: Docking Connector; Latch and Locking mechanism - 30;000 cycles

  • Port Replicators:

    • Getac certified electronics
    • (1) Ethernet - RJ45
    • (3) USB 2.0 (500mA) - 4 pin
    • (1) USB 3.0 (900mA) - 9 pin
    • (1) VGA D-sub - 9 pin
    • (1) HDMI - 19 pin
    • Tri RF Pass-through (optional) - SMA
    • Power input - 19VDC
    • (1 each) Speakers / Microphone

  • Antenna Pass-through:

    • Tri RF

  • Device Type:

    • Tablet

  • Industry:

    • Fire/Rescue
    • Material Handling
    • Public Safety
    • Utility

  • Port Replication:

    • Full

  • Brand:

    • Gamber-Johnson

  • Sub Type 1:

    • Docking Kit

  • Notes:

    Compatible with the Getac F110 Gen 7 tablet computer and backwards compatible with previous versions of the F110 tablet.

    Docking station is compatible with InfoCase FM-MFX-F110G6 G6 Tablet ModuFlex.
