Panasonic TOUGHBOOK G2/G3 Standard Full Dock (Powered Serial, Dual RF)

$1,393.00

Item Number: 7160-2184-22

Description

For crews with powered serial gear and vehicle antennas, every connection has a job. This Standard Full dock combines powered RS-232, dual SMA RF pass-through, Ethernet and USB for TOUGHBOOK® G3 or G2. Front USB-C remains convenient during the shift, and rear ports support installed equipment. With room for compatible G2 field accessories, the Standard design helps keep the setup familiar as the fleet changes tablets.

Add to Quote
Shipping — Approximate Lead Time Given at Order Entry
Where To Buy Where to Buy
URL copied to clipboard
Product Sheet Installation Guide
View Full Line Catalog

  • Weight

    2.37 lbs / 1.08 kg

  • Height

    9.67 in / 24.56 cm

  • Width

    11.18 in / 28.40 cm

  • Depth

    5.25 in / 13.35 cm w / Studs 4.33 in / 11.00 cm w / o Studs

Features:

  • Make every connection count. Keep the tablet linked to the equipment crews use throughout the shift.
  • Connect within reach. Front USB-C makes it easier to attach a peripheral without reaching behind the tablet.
  • Keep fixed devices connected. Two rear USB-C ports, USB-A and 1Gbps Ethernet serve installed equipment.
  • Give serial peripherals the port they need. Full replication adds powered RS-232 and DP Alt Mode on rear USB-C.
  • Bring the antennas along. Dual SMA pass-through lets the tablet use installed external antenna connections.
  • Choose the power connection that fits. A compatible 15 VDC vehicle adapter is sold separately.
  • One workspace across G2 and G3. Compatible with both tablets; the Standard design accommodates compatible G2 field accessories.
  • Confidence for mobile work. TOUGHBOOK Certified with MIL-STD-810H testing and a three-year limited warranty.


Purchase this product through a Reseller in your area.

  • Model:

    • TOUGHBOOK G2
    • TOUGHBOOK G3

  • Device OEM:

    • Panasonic

  • Warranty:

    • 3 Year Limited Warranty
    • Extended Warranty/Gamber Guard Options Available

  • Power Supply:

    • Power adapter is not included, please use one of the following:
    • Lind 120W Automobile Bare Wire Leads Power Adapter for Panasonic (7300-0461)
    • Power Adapter – Panasonic 120W – Auto Adapter (7300-0747)
    • LIND 12-32V Material Handling Isolated Power Adapter (7300-0464)
    • LIND 20-60V Material Handling Isolated Power Adapter (7300-0465)
    • LIND 72-110V Material Handling Isolated Power Adapter (7300-0417)

  • Testing Specifications:

    • TOUGHBOOK certification in progress
    • MIL-STD 810H Shock/Vibration Tested
    • MIL-STD 810H Environmental Testing: Humidity, High/low temperature, (storage/operational)
    • Cycle Tested: 30K cycles, docking connector, latching & locking mechanisms
    • RoHS, FCC, CE, UKCA
    • SAE J1455 Shock Crash Hazard Test

  • Port Replicators:

    • 1 x RJ45 Ethernet 1Gbps
    • 1 x USB-A 5Gbps, 1.5A
    • 1 x USB-C 5Gbps, 0.9A
    • 1 USB-C 5Gbps, 1.5A (With DP Alt Mode)
    • 1 x USB-C 480Mbps, 0.5A (Front)
    • 1 x RS-232 Serial
    • 1 x 15 VDC Power Input

  • Antenna Pass-through:

    • Dual RF (SMA)

  • Device Type:

    • Tablet

  • Industry:

    • Fire/Rescue
    • Intermodal
    • Logistics
    • Material Handling
    • Public Safety
    • Utility

  • Port Replication:

    • Full

  • Brand:

    • Gamber-Johnson

  • Sub Type 1:

    • Dock
