Panasonic TOUGHBOOK G2/G3 Slim Full Dock (Powered Serial, No RF)

$1,224.00

Item Number: 7160-2186-20

Description

Powered serial equipment belongs in the vehicle plan, even when every inch counts. This 3.85-inch-deep Slim Full dock gives compatible RS-232 peripherals a powered serial connection alongside Ethernet and USB for TOUGHBOOK® G3 or G2. Front USB-C is close to the crew; rear connections serve installed gear without crowding the workspace. It is a practical way to keep the equipment you depend on connected while making room for everything else in the cab.

Add to Quote
Shipping — Approximate Lead Time Given at Order Entry
Where To Buy Where to Buy
URL copied to clipboard
Product Sheet Installation Guide
View Full Line Catalog

  • Weight

    2.175 lbs / 0.99 kg

  • Height

    11.17 in / 28.37 cm

  • Width

    9.66 in / 24.54 cm

  • Depth

    3.85 in / 9.78 cm

Features:

  • Leave room for the rest of the job. The 3.85-inch profile is 1.02 inches shallower than the Standard design.
  • Keep a connection close. The front USB-C port stays accessible to the crew during the shift.
  • Free the front of the workspace. Rear USB and Ethernet ports support the gear that stays in the cab.
  • Make room for powered serial. Powered RS-232 serves compatible peripherals; rear USB-C supports DisplayPort Alt Mode.
  • Choose the connection set you need. The no-RF configuration fits vehicles without external tablet antennas.
  • Match power to the installation. Select a compatible vehicle power adapter separately.
  • One family across generations. Designed for TOUGHBOOK G3 and backward compatible with G2.
  • Built to keep up. TOUGHBOOK Certified and cycle tested through 30,000 docking, latch and lock uses.


Purchase this product through a Reseller in your area.

  • Model:

    • TOUGHBOOK G2
    • TOUGHBOOK G3

  • Device OEM:

    • Panasonic

  • Warranty:

    • 3 Year Limited Warranty
    • Extended Warranty/Gamber Guard Options Available

  • Power Supply:

    Power adapter is not included, please use one of the following:


    • Lind 120W Automobile Bare Wire Leads Power Adapter for Panasonic (7300-0461)
    • Power Adapter – Panasonic 120W – Auto Adapter (7300-0747)
    • LIND 12-32V Material Handling Isolated Power Adapter (7300-0464)
    • LIND 20-60V Material Handling Isolated Power Adapter (7300-0465)
    • LIND 72-110V Material Handling Isolated Power Adapter (7300-0417)

  • Testing Specifications:

    • TOUGHBOOK certification in progress
    • MIL-STD 810H Shock/Vibration Tested
    • MIL-STD 810H Environmental Testing: Humidity, High/low temperature, (storage/operational)
    • Cycle Tested: 30K cycles, docking connector, latching & locking mechanisms
    • RoHS, FCC, CE, UKCA
    • SAE J1455 Shock Crash Hazard Test

  • Port Replicators:

    • 1 x RJ45 Ethernet 1Gbps
    • 1 x USB-A 5Gbps, 1.5A
    • 1 x USB-C 5Gbps, 0.9A
    • 1 USB-C 5Gbps, 1.5A (With DP Alt Mode)
    • 1 x USB-C 480Mbps, 0.5A (Front)
    • 1 x RS-232 Serial
    • 1 x 15 VDC Power Input

  • Antenna Pass-through:

    • No RF

  • Device Type:

    • Tablet

  • Industry:

    • Fire/Rescue
    • Intermodal
    • Logistics
    • Material Handling
    • Public Safety
    • Utility

  • Port Replication:

    • Full

  • Brand:

    • Gamber-Johnson

  • Sub Type 1:

    • Dock
