7170-1299-00

$1,389.00

Item Number: 7170-1299-00

Description

Give the tablet a ready place in a hardwired vehicle workspace. This kit combines a Standard Full dock for TOUGHBOOK® G3 and G2 with a Lind 120W bare-wire adapter, bringing power and docking together in one selection. Ethernet, USB and non-powered RS-232 support installed equipment, while front USB-C makes an everyday peripheral easier to reach. The Standard design also accommodates compatible G2 field accessories as crews transition to G3.

Add to Quote
Shipping — Approximate Lead Time Given at Order Entry
Where To Buy Where to Buy
URL copied to clipboard
Product Sheet Installation Guide
View Full Line Catalog

  • Weight

    See Individual Components.

  • Height

    See Individual Components.

  • Width

    See Individual Components.

  • Depth

    See Individual Components.

Features:

  • A dedicated place to connect. Bring the tablet and vehicle equipment together in one Standard workspace.
  • Keep a connection close. The front USB-C port stays accessible to the crew during the shift.
  • Free the front of the workspace. Rear USB and Ethernet ports support the gear that stays in the cab.
  • Connect the equipment already in use. Full replication includes non-powered RS-232 and rear USB-C display support.
  • A focused no-RF option. Select this version when antenna pass-through is not part of the vehicle plan.
  • Complete the vehicle power choice. Includes the Lind 120W adapter with bare-wire leads.
  • Keep the G2 setup intact. Supports compatible G2 extended battery, rear hand strap, smart card reader and bumper guards.
  • Built to keep up. TOUGHBOOK Certified and cycle tested through 30,000 docking, latch and lock uses.


Kit Includes:

  • Dock: 7160-2184-00 – Standard Full Dock (No RF, Non-Powered Serial)
  • Power Supply: 7300-0461 – Lind 120W Auto Power Adapter (Bare Wire)

Purchase this product through a Reseller in your area.

  • Model:

    • TOUGHBOOK G2
    • TOUGHBOOK G3

  • Device OEM:

    • Panasonic

  • Warranty:

    • Individual Item Warranty Applies

  • Power Supply:

    Includes Power Supply:

    • Lind 120W Automobile Bare Wire Leads Power Adapter for Panasonic (7300-0461)

  • Testing Specifications:

    • TOUGHBOOK certification in progress
    • MIL-STD 810H Shock/Vibration Tested
    • MIL-STD 810H Environmental Testing: Humidity, High/low temperature, (storage/operational)
    • Cycle Tested: 30K cycles, docking connector, latching & locking mechanisms
    • RoHS, FCC, CE, UKCA
    • SAE J1455 Shock Crash Hazard Test

  • Port Replicators:

    • 1 x RJ45 Ethernet 1Gbps
    • 1 x USB-A 5Gbps, 1.5A
    • 1 x USB-C 5Gbps, 0.9A
    • 1 USB-C 5Gbps, 1.5A (With DP Alt Mode)
    • 1 x USB-C 480Mbps, 0.5A (Front)
    • 1 x RS-232 Serial
    • 1 x 15 VDC Power Input

  • Antenna Pass-through:

    • No RF

  • Device Type:

    • Tablet

  • Industry:

    • Fire/Rescue
    • Intermodal
    • Logistics
    • Material Handling
    • Public Safety
    • Utility

  • Port Replication:

    • Full

  • Brand:

    • Gamber-Johnson

  • Sub Type 1:

    • Dock
