Panasonic TOUGHBOOK G2/G3 Slim Lite Dock Kit (No RF) with 120W Bare Wire Power Supply

$1,296.00

Item Number: 7170-1301-10

Description

Make the most of the cab without overcomplicating the connection list. This Slim Lite kit gives TOUGHBOOK® G3 and G2 a shallow 3.85-inch dock with the Ethernet and USB ports crews use every day. Front USB-C is convenient for a peripheral that comes and goes; rear ports support the devices that stay. The included Lind 120W bare-wire adapter completes the hardwired power choice, creating a focused vehicle setup without a serial port.

Add to Quote
Shipping — Approximate Lead Time Given at Order Entry
Where To Buy Where to Buy
URL copied to clipboard
Product Sheet Installation Guide
View Full Line Catalog

  • Weight

    See Individual Components.

  • Height

    See Individual Components.

  • Width

    See Individual Components.

  • Depth

    See Individual Components.

Features:

  • Leave room for the rest of the job. The 3.85-inch profile is 1.02 inches shallower than the Standard design.
  • Keep a connection close. The front USB-C port stays accessible to the crew during the shift.
  • Free the front of the workspace. Rear USB and Ethernet ports support the gear that stays in the cab.
  • Keep the connection mix focused. USB and Ethernet are available; Lite omits RS-232 and DP Alt Mode.
  • Match the vehicle installation. No RF pass-through suits vehicles that do not need external antenna connections.
  • Put power in the same selection. Includes a Lind 120W bare-wire adapter for a hardwired vehicle connection.
  • One family across generations. Designed for TOUGHBOOK G3 and backward compatible with G2.
  • Built to keep up. TOUGHBOOK Certified and cycle tested through 30,000 docking, latch and lock uses.


Purchase this product through a Reseller in your area.

  • Model:

    • TOUGHBOOK G2
    • TOUGHBOOK G3

  • Device OEM:

    • Panasonic

  • Warranty:

    • Individual Item Warranty Applies

  • Power Supply:

    Includes Power Supply:

    • Lind 120W Automobile Bare Wire Leads Power Adapter for Panasonic (7300-0461)

  • Testing Specifications:

    • TOUGHBOOK certification in progress
    • MIL-STD 810H Shock/Vibration Tested
    • MIL-STD 810H Environmental Testing: Humidity, High/low temperature, (storage/operational)
    • Cycle Tested: 30K cycles, docking connector, latching & locking mechanisms
    • RoHS, FCC, CE, UKCA
    • SAE J1455 Shock Crash Hazard Test

  • Port Replicators:

    • 1 x RJ45 Ethernet 1Gbps
    • 1 x USB-A 5Gbps, 1.5A
    • 1 x USB-C 5Gbps, 0.9A
    • 1 USB-C 5Gbps, 1.5A (Without DP Alt Mode)
    • 1 x USB-C 480Mbps, 0.5A (Front)
    • 1 x 15 VDC Power Input

  • Antenna Pass-through:

    • No RF

  • Device Type:

    • Tablet

  • Industry:

    • Fire/Rescue
    • Intermodal
    • Logistics
    • Material Handling
    • Public Safety
    • Utility

  • Port Replication:

    • Lite

  • Brand:

    • Gamber-Johnson

  • Sub Type 1:

    • Docking Kit
